D.3D - 3D adjustable drill-in hinge

Previous Product | Next Product
Product Description

D.3D
3D adjustable drill-in hinge with Ø14 and Ø16

3D adjustable drill-in hinge for doors or windows, with Ø14 or Ø16 and in Stainless Steel or Zinc-coated Steel
• Load capacity (3 steel hinges): 90Kg
• Dimensions: Ø14x82mm and Ø16x82mm



Possibility of 3D adjustment:
- Vertical adjustment of 4mm with threaded conical bolt 1 that operates the stainless steel-coated rotating sphere on the adjustable drill-in hinge 4
- Horizontal/perpendicularity adjustment of drill-in hinge 3
- Pressure/depth adjustment
• Self-lubricating sleeve 2
• Suitable for fire doors
• CE Certification
• Cover caps in several finishes
• Appropriate molds for application available

For more information see the technical information image.

Read More
Brand : AGB
€0,00 VAT inc.
XXX
Unit

Usually in stock, ships within 3 business days
