D.221 - Pivot hinge

Previous Product | Next Product
Product Description

D.221
Pivot Hinge

• Hinge for furniture doors
• Detachable
• For door thicknesses of 12 to 21mm
• Press fit
• Maximum door opening angle 140º
• One pair per mounting
• Material: Plastic
• Fixing screws supplied separately

Notes:
- To detach the door, insert a small screwdriver into the hole located in the door edge.
   Use the screwdriver to lift the spring-loaded pin inside the lower bushing.
   Important: be sure to match the holes in the door and bushing.

- To increase or reduce the gap, turn the tab on its pivot bearing.
   Once adjusted, secure the tab in position using a small wood screw.

For more information see the technical information image.

Read More
Brand : handlie
€0,00 VAT inc.
XXX
Box 20
Professional application

Usually ships within 8 business days.
